TPM+ rotary servo actuators

  • TPM+ dynamic: Power with small installation space and very smooth running Actuator with two-stage gearbox designed primarily for rotary applications

  • TPM+ high torque: High torsional rigidity and superior power density. Two or three-stage servo actuator for heavy-duty applications

  • TPM+ power: high torque, small installation space Single or two-stage motor/gearbox combination for linear and rotary applications

More productive – more efficient – more precise

With the servo actuator TPM+ , precision planetary gearboxes and synchronous servo motors are integrated without a clutch for a unit that is flexible in its application. That wins customers over with its power, torque and torsional rigidity. In combination with short overall lengths, high power-density and smooth running: this marks a whole new level of performance – along with practical, graduated performance settings that ensure greater operating efficiency in all your production applications.

Downloads

Customized solutions

We will develop a solution for you that is tailored to your drive needs. You will benefit from our years of experience, our highly skilled staff and our services. Please contact us.

Contact form

WITTENSTEIN alpha GmbH - Walter-Wittenstein-Str. 1

WITTENSTEIN alpha GmbH

Walter-Wittenstein-Str. 1

97999 Igersheim (Germany)

+49 7931 493-0

+49 7931 493-200

www.wittenstein-alpha.com

  • Technical data
  • Options
  • System expansions
  • Your benefits
  • Versions



TPM+ dynamic

  • 5 sizes
  • Max. output speed 55 to 375 RPMs
  • Max. output torque 30 to 1300 Nm
  • Max. motor performance 0.8 to 15.2 kW
  • Installation length 113 to 332 mm

TPM+ high torque

  • Four sizes
  • Max. output speed 20 to 220 RPMs
  • Max. output torque 230 to 3100 Nm
  • Max. motor performance 1.7 to 55.1 kW
  • Installation length 183 to 491 mm

TPM+ power

  • Five sizes
  • Max. output speed 45 to 1500 RPMs
  • Max. output torque 15 to 1600 Nm
  • Max. motor performance 1.0 to 34.5 kW
  • Installation length 149 to 411 mm







You can choose from:


  • Design "enhanced corrosion protection"
  • Permanent magnet holding brake
  • EnDat 2.1 or Hiperface Absolute encoder
  • TTL incremental encoder with Hall effect signal
  • DRIVECLiQ, EnDat 2.2, Hiperface DSL (on request)
  • KTY and PTC temperature sensors
  • Intermediate circuit voltage of 48, 320 or 560V DC
  • Straight or angled integral sockets





  • Wide selection of racks and pinions; on request, the pinion can be welded directly to the output flange.
  • Cables for power and signaling, drag-chain-compatible, pre-assembled for selected servo controllers
  • The simco® drive servo amplifier is available as a switch cabinet version with protection class IP20 and as a decentralized version with protection class IP65. With a voltage range from 24 to 48 V DC and a rated power of up to 2 kW, the simco® drive servo amplifier can be used for high-precision applications.







Increased productivity
The benefits for your machinery and plants: An actuator with a low moment of inertia and an extremely rigid drive train provide for maximum precision and power. A decisive increase in productivity


Higher efficiency
Low torsional backlash, an output bearing with a high degree of tilting rigidity and integration of the gearbox pinion in the motor shaft result in: smaller motors, reduced energy consumption and lower investment costs.

Higher precision
Low levels of operating noise due to helical teeth and outstanding control properties provide enhanced precision in your machinery and plants. The result: truly cost-effective products







Highly compact motor/gearbox unit consisting of a precision planetary gearbox and permanent-magnet-excited synchronous servo motor with resolver UL certified


Three designs for different areas of application

1. TPM+ dynamic: dynamic motor version in combination with two-stage planetary gearbox for rotary applications in packaging, robotics and automation

2. TPM+ high torque: powerful motor and highly rigid planetary gearbox in two and three-stage designs for applications in processing machinery and handling of large masses

3. TPM+ power: powerful motor with one or two-stage planetary gearbox for demanding linear and rotary applications in processing and handling
